This is a collection of GEOS programming tips 'n' tricks that I've collected over the years. I continue to learn this fascinating subject, and new tips are being added as I come across things that I think might be helpful to others.

Assembling and Linking GEOS Applications
General Programming Tips
API usage tips
geoDebugger commands
geoDebugger macros
geoProgrammer Quirks
Compute!'s Gazette geoProgrammer example

Assembling and Linking GEOS Applications

Don't use expressions to get the length of a data area within an instruction. For example:
```
lda     #bufEnd-buffer
...
buffer: .block 128
bufEnd:
```
The assembler may generate incorrect object code on subsequent instructions if you do. Instead, do it like this:
```
lda     #bufLen
...
buffer: .block 128
bufEnd:
bufLen  =      bufEnd-buffer
```
If your program is made up of several source files and you are including symbol files and macros, take care not to pass symbols to the linker more than once; it fills up the symbol table needlessly. If you have a large project and you don't do this, you'll find that as you go further and further into your VLIR modules with the debugger, you'll see fewer and fewer symbols. Another good idea is to create your own symbol file with only the ones you need rather than including geosSym.
The includes for your first source file should look something like this:
```
.if     Pass1
        .include shadowSym
        .include shadowMac
.endif
```
All subsequent source files (including VLIR modules, even if they are made up of a single source file) should have their includes declared like this:
```
.if     Pass1
        .noeqin
        .noglbl
        .include shadowSym
        .include shadowMac
        .glbl
        .eqin
.endif
```

General Programming Tips

To create the icon for an application (24x21 pixels), you can paste it directly into the source code for the application's header module; this will work if it you cut it at 3x3 cards in geoPaint (24x24 pixels). geoPaint will not copy any finer than on card boundaries. On the other hand, if you are creating a new file programmatically and building a header template in code (to pass to SaveFile in r9), that will not work and you have to convert the icon to .byte directives and enter it by hand.
When designing your own icons with text labels, if you want to make them look like the system icons, give them a size of 6 cards (48 pixels) wide by 16 pixels high, and use University 12pt bold font; the icon border should have a one-pixel shadow. You can line them up in geoPaint by setting alternate 8x8 cards to a white background in a checkerboard pattern. This makes copying them to photo scraps easy, but there's no good way to type text into them in geoPaint. Your best bet is to add the text near the icon but outside it, then use pixel edit mode to manually create each character. It's a lot of work, but it gives you the best-looking icons.
Both DoIcons and DoMenu have support for setting the mouse position when they are called. DoIcons has X and Y mouse position coordinates within the icon table, and DoMenu takes a value in .A indicating which menu item the mouse should be positioned over after calling it (zero-based). However, repositioning the mouse can be disabled by supplying zeroes for the mouse position in the icon table, while there is no such ability in DoMenu. The DoMenu API description in the Hitchhiker's Guide to GEOS provides a code example for a workaround: disable interrupts, push the mouse position onto the stack, call DoMenu with 0 in .A, then restore the mouse position and the interrupt status. Works great!
If you're modifying menus while they're active (changing the values of pointers in the menu table), you don't have to call DoMenu again to make the changes visible. For example, you may want to disable a menu item by changing the text pointer to reference italicized text and replace the dispatch routine with an rts. However, this only works if the menu is not currently visible. If you're changing the text of a menu item while it's pulled down, you need to call ReDoMenu.
If you're checking for a double-click, you'll find the symbol for where the countdown value is stored in geosSym (dblClickCount), but not the constant for the default value (CLICK_COUNT). The correct declaration is
```
CLICK_COUNT=30
```
For more information on detecting double-clicks in various situations, see "MainLoop and Icon Event Handlers" in the "Icons, Menus, and Other Mouse Presses" section of the Hitchhiker's Guide to GEOS (it's on page 5 of that section). Read the "Other Mouse Presses" section on page 18 if you're using otherPressVector. Oh, and if you're using otherPressVector, make sure to disable interrupts while you're changing it:
```
php
sei
LoadW  otherPressVector,myCode
plp
```
GEOS maintains date and time variables, so if the machine's time is set correctly, you can read them easily. These are the official equates:
```
year==$8516
month==$8517
day==$8518
hour==$8519
minutes==$851a
seconds==$851b
```
Note that minutes and seconds are plural.
GEOS uses the time-of-day clock on CIA #1 to store hour, minutes, and seconds. So if you want to set the time, you need to set the above variables as well as setting the TOD clock for hour, minutes, and seconds. Note that writing to the hours register stops the clock until you write to the tenths-of-second register! Here's some sample code from my UltimateTime autoexec:
```
jsr	enableIO
php
sei
lda	$dc0f	        ;CIA #1
and	#$7f	        ;set time, not alarm
sta	$dc0f
MoveB	cHour,$dc0b     ;this stops the clock!
MoveB	cMinutes,$dc0a
MoveB	cSeconds,$dc09
MoveB   0,$dc08         ;this restarts the clock
plp
jsr	restoreIO
```
Consult a reference like the Abacus Advanced Machine Language Book for the format these registers expect.
You can tell whether an autoexec is running during bootup or as the result of the user double-clicking its icon by checking the value of firstBoot ($88C5, it's listed in geosSym). The only documentation I found for it is in the variable reference at the end of the Hitchhiker's Guide to GEOS, where it says "This flag is changed fron 0 to $FF when the deskTop comes up after booting." I wrote a test program to verify this, which you can find source and executable for on this D64 image. You can also view the source as ASCII plaintext.

API Usage Tips

InitForIO is not re-entrant. It saves state, which is restored by DoneWithIO. What this means is that if you call InitForIO a second time without having called DoneWithIO in between, the saved state is overwritten and you can't return to it. When you do call DoneWithIO, the kernel will not be banked back in and the machine will crash as soon as any GEOS APIs are called.
InitForIO is quite expensive, since its main purpose is to set up for disk access with the GEOS fastloader running (in fact, it resides within the disk driver, as the first jump table entry). If you want to do any I/O on the IEC bus, you need to call it, but if all you want to do is bank in the I/O chips (e.g. for accessing the SID registers), you might want to try something like this:
```
enableIO:  php
           sei
           lda $01
           sta ioSave  ;save memory configuration
           and #$f8
           ora #$05    ;bank in I/O
           sta $01
           plp
           rts
restoreIO: php
           sei
           lda ioSave  ;restore previous configuration
           sta $01
           plp
           rts
ioSave:    .block 1
```
Note that these routines are also not re-entrant!
One other thing to consider: InitForIO trashes both the accumulator and the Y register (although X is preserved), while the above only trashes the accumulator.
GetString keeps running during MainLoop, until the user hits Return. If you need to terminate string input manually (e.g. as part of a menu or icon handler), just use this code, which essentially fakes a keypress:
```
LoadB keyData,#$0d
lda   keyVector
ldx   keyVector+1
jsr   CallRoutine
```
Since GetString keeps running during MainLoop, you may have a problem if you call PutString at the same time, because the two APIs share some common system variables. I encountered this when a process handler called PutString while GetString was running; this is the code I use to save and restore those variables:
```
PushB $87cf           ;stringLen
PushB $87d0           ;stringMaxLen
PushB alphaFlag       ;save cursor state
PushW leftMargin
PushW rightMargin
PushW StringFaultVec
...
jsr PutString
...
PopW StringFaultVec
PopW rightMargin
PopW leftMargin
PopB alphaFlag
PopB $87d0
PopB $87cf
```
Be careful about adjusting windowTop (which sets the upper bounds for text clipping). This limit is considered when menus are drawn, so if you set it lower than your menus, their text won't be redrawn if the user drops one down and then faults (moves his mouse off the menu). Set it only when needed, and restore it afterward.
The section on "Text, Fonts, and Keyboard Input" in the Hitchhiker's Guide is pure gold for learning advanced techniques... but there's a coding error in the section on clipping. On page 12 of this section, there's a string fault routine that is supposed to avoid the bug where on a right margin fault, PutString keeps trying to find a character that will fit. The routine is supposed to advance the pointer to the null byte at the end of the string; unfortunately, there's an off-by-one error, and it will leave the pointer on the last valid character instead. Try this:
```
PutStrFault: ldy #0
10$          inc r0L     ;advance to next character
             bne 20$
             inc r0H
20$          lda (r0),y  ;read it
             bne 10$     ;end of string?
             rts         ;yes, we've faked out PutString
```
Be aware that the VLIR record handling APIs change the positions of other records! AppendRecord inserts an empty record after the current record and moves the rest down one; InsertRecord does the same but inserts the record before the current record. DeleteRecord deletes the current record and moves all following records up one. You can delete a record and leave a "hole" in the records by calling WriteRecord with a length of zero (see the Hitchhiker's Guide to GEOS).
When creating a VLIR file, you may want to initialize every record so that you can just use WriteRecord later (without the reordering that AppendRecord and InsertRecord cause). Just call AppendRecord on the newly-created file in a loop until it returns OUT_OF_RECORDS (9) in the X register. What this does is change the index pointer of each record from $00,$00 (never used) to $00,$ff (empty).
When using SaveFile to create a new file, you need to check first to make sure a file by that name doesn't already exist. Otherwise, the file will be written anyway and you will end up with two files with the same name on the same disk! This seems like an egregious bug, so caveat utilitor.
DoDlgBox: If you're using DBGETSTRING in a dialog box, don't use an OK icon. The string won't get null-terminated until the user hits Return, so if he types a large number of characters and then backspaces over some of them, they will all be returned as part of the buffer (this is why GEOS filename dialogs don't have an OK icon). Check for DBGETSTRING in r0L when DoDlgBox returns instead.
DoDlgBox and DB_USR_ROUT: When you include a user routine in your DB table, it is called in the order the commands are listed in the table. This raises all sorts of interesting possibilities for drawing portions of a dialog box. In fact, you can use it to debug the dialog box as it's being drawn by setting a breakpoint in the user routine: it will break into the debugger at that point in the table, and you can use F7 to see the partially drawn dialog box!
Don't use LdFile. The BSW programmer's guide says that the variables loadOpt and and loadAddr can be used to control whether the file's load address is overridden, but doesn't say where these variables live (geosSym doesn't either). Boyce says $886B and $886C, but that didn't work for me, so I looked in the Hitchhiker's Guide, which had this to say:
"All versions of LdFile to date under Commodore GEOS are unusable because the load variables... (loadOpt and loadAddr) are local to the Kernal and inaccessible to applications. Fortunately this is not a problem because applications can always go through GetFile to achieve the same effect." Caveat utilitor.

In my experience, GetRandom isn't very random. I wrote these routines instead, which use the SID chip to generate pseudo-random numbers (the article Examination of SID noise waveform was very helpful). Call primeRnd during program initialization, then use sidRnd when you need a pseudo-random number. The I/O chips are banked in and out using the technique described above.

For example, to roll a 20-sider, pass 20 in r2; the result in r1 will be in the range 0-19.

;-----------------------------------------------------------
; Prime SID chip to generate random numbers.
;-----------------------------------------------------------
primeRnd: jsr enableIO
          lda #0
          sta $d40e        ;voice 3 frequency low
          lda #$80         ;frequency to $8000
          sta $d40f        ;voice 3 frequency high
          sta $d412        ;noise waveform, gate off 3
          jsr restoreIO
          rts
;-----------------------------------------------------------
; Pseudo-random number generator (uses SID chip).
; pass:      r2, high limit (1-based)
; return:    r1, pseudo-random number (0-based)
; destroyed: .A, .X, .Y, r1, r8, r9
;-----------------------------------------------------------
sidRnd:   LoadW r1,65535   ;r2 loaded on entry
          ldx #r1
          ldy #r2
          jsr Ddiv
          MoveW r1,r2      ;r2 = 65535 / high limit
          jsr enableIO
          lda $d41b
          sta r1L
          ldx #7           ;delay at least 32 cycles
10$       dex
          bne 10$
          lda $d41b
          sta r1H
          jsr restoreIO
          ldx #r1
          ldy #r2
          jsr Ddiv         ;r1 = r1 / r2
          rts

And remember, kids: as John von Neumann said, "Anyone who considers arithmetical methods of producing random digits is, of course, in a state of sin."

geoDebugger commands

Here's a handy cheat sheet of geoDebugger commands; see the manual for full descriptions.

geoDebugger macros

geoDebugger has a very powerful macro facility, but it's not the easiest thing to work with, mainly because macros have to be quite small (You'll see the message "Error: macro nesting" a lot). But if you have a complex function you want to perform, it is possible to break it out into many small macros to accomplish your task. (You'll naturally want to write the entire thing in geoWrite.) In my case, I wanted to have a macro that would print detailed information about a menu table including its orientation, constraints, and menu items; it took a dozen tiny macros to accomplish it.
Here is the entire macro (or rather, macros), and here are some excerpts with comments:
```
if @(arg0)=80,print"type: SUB_MENU"[cr]
```
This line expects an address and reads the byte at that address, using the @ operator. The value is tested against $80 (hex is the default radix).
```
if @(arg0)=c0||(@(arg0)&3f)!=0,print @(arg0):"unknown type: "[cr]
```
Another lookup. If only bits 6 and 7 are set, or if any of the low bits are set, print the value preceded by the heading "unknown type: ".
```
print @@(arg0):8b'"menu item text: "[cr]
```
This one prints eight bytes in character format (8b') with the heading "menu item text: ", starting at the address (@@) located at the argument.
```
.macro showitem
setu 1,arg0+(5*u.fn)[cr]
menuitem u.1[cr]
.endm

.macro menuitms
print @(arg0+6)&3f:."no. items: "[cr]
setu 0,(@(arg0+6)&3f)-1[cr]
for .0:u.0,showitem (arg0+7)[cr]
.endm
```
These two macros show several features. In menuitms, we set user register zero (u.0) with the setu command. We are setting it to the number of items in the menu (lower six bits at offset six in the menu structure) minus one, to use as a counter. We then call showitem in a for loop. This macro was broken out separately after getting the infamous nesting error. We pass the first byte of the menu item list (offset seven); the called macro sets user register one (u.1) to the beginning of the current menu item structure using the loop counter u.fn (menu item structures are five bytes long), and calls the menu item display macro.
Here's some sample output (note that the dispatch addresses are all the same for desk accessories):
```
>menu geosMenu
top/bottom: .15  .99
left/right: .0  .100
type: VERTICAL|CONSTRAINED
no. items: .6
menu item text: info.set
type: MENU_ACTION
dispatch: $0437
menu item text: text man
type: MENU_ACTION
dispatch: $0561
menu item text: photo ma
type: MENU_ACTION
dispatch: $0561
menu item text: ScreenPh
type: MENU_ACTION
dispatch: $0561
menu item text: ruler1.5
type: MENU_ACTION
dispatch: $0561
menu item text: printIt1
type: MENU_ACTION
dispatch: $0561
>
```
I guess I could refine the macro that prints the menu item text...

geoProgrammer Quirks

Don't let your source files get too big. I once had an issue where all eight source files making up an app assembled correctly, but the linkage editor failed on an "Expression cannot be resolved" error. The error message then printed the offending line of source... which contained only the single character 'p'. My first thought was that I had bumped the keyboard and introduced a stray character in the source, but then it wouldn't have assembled. I went over the source file with a fine-toothed comb and didn't find anything, so I finally decided to split the file into two, and voilà! the linker was happy.
If you are writing a VLIR application, make sure the header source matches the linkage directive file. If the link file says .vlir and the header says .byte SEQUENTIAL, your resident module will contain the VLIR index instead of its code.
Even though geoProgrammer 1.1 fixed a lot of bugs, it will still act squonky once in a while, especially with large projects. I once got a "symbol defined more than once" from the linker that was definitely not an error; I finally just looked up the symbol and replaced it with the absolute address on that line, and the error message went away. Sometimes you have to get a little creative.
One thing you can count on regardless of which geoProgrammer version you use is that the page and line numbers in an error listing will sometimes be wrong. This is partly because the assembler seems to count expanded macros as multiple lines of source, but you'll also see incorrect page numbers. For example, I once assembled a source file that had a branch out of range near the end of page 6; the error message pointed to page 7, line 84. I made a mistake when I fixed it, and on the next assembly, the error message said page 6, line 84. I've also seen an error message that said "page 4, line >2" (no, that's not a typo).
You may also get a "Branch out of range" error when there doesn't appear to be one; this usually happens in an area with a lot of local labels where global labels are far apart. Experienced GEOS programmers know that adding another global label amongst the locals will usually result in a clean assembly.

Compute!'s Gazette geoProgrammer example

A geoProgrammer sample program was published in the October 1988 issue of Compute!'s Gazette (available on Bombjack). There's a review of geoProgrammer on page 59, and the sample program is on page 76; Bruce Thomas has typed in the source and provided the icons as well. Here is the D64 he sent with all the files on. Note: there's a bug in the program, can you find it? Since I'm sure Bruce put it there on purpose as an exercise for the reader, let's break out geoProgrammer and take up the challenge!

I'm going to assume that you're running GEOS 2.0 and using an REU, which geoDebugger really needs.
Looking at the code, we see that there's an undocumented feature: once you click the icon that appears at start time, you can enter some text in a box that appears on the screen as soon as you hit a key. Try it on the "unfixed" version... you will get a system crash (it works partially under Wheels, but that's another story for another day).
Assemble the source files Ex and ExHdr, then run the linker, passing the file ex.lnk.
Double-click the resulting debugger file CG-Example.dbg to start geoDebugger.
We see from the source code that when the initial icon is pressed at DoIcon1, a key handler is set up with the address of DoKey. Have a quick look at that code by typing a DoKey and cursoring down until you hit the call to jsr GraphicsString, then hit Return. We're looking at the expansion of the macro LoadW r0,DrawBox.
Type sym DrawBox; we see that the code is passing the correct address to GraphicsString.
OK, let's step through it to see where the problem lies. Set a breakpoint by typing setb DoKey, then go to start the program.
Click the icon to dismiss it, then type a key. The debugger stops at DoKey. So far, so good.
Now step through the code using t (top-step). We're OK until we reach the call to jsr GraphicsString, but then get a crash. Type rboot to reboot GEOS, then restart the debugger as above.
Hmmm, it looks like GraphicsString doesn't like the data we're passing it. Let's examine it by using the command d DrawBox, which will give us a hex hex dump of the table.
Now open your trusty Hitchhiker's Guide to GEOS and find the API docs for GraphicsString. Let's compare the data in the table with what the API is expecting.
05 means NEWPATTERN, and it's followed by a zero byte for the pattern. No problem there.
The next byte is 56... wait, that's not a valid command! We have found the bug! Looking ahead in the source code, we see a RECTANGLETO command, which should be preceded by a MOVEPENTO command. Maybe that's all that was missing, as the following bytes would then make sense (56 00 and 5A). Comparing the source with the original in the Compute! article, we find that this is indeed the case. Insert the missing line (.byte MOVEPENTO) in the Ex file, reassemble it, and rerun the linker as above. The bug is squashed!
You can find the fixed code (with object files, geoDebugger file, and symbol table) here. For extra credit, try implementing these enhancements:
- Center the initial "Click here to continue" icon on the screen (yes, I'm a neat-freak).
- Add a message on the screen to let the user know they can hit a key to enter some text.
- When the user hits Return to terminate the text input, show a dialog saying "You entered...".

Not to be outdone, Bruce responded with an enhanced version of the program, which you can find here. Bruce scores the extra credit points (note his use of picW and picH after the icon graphic)! Now who else wants to join the fray? What else can you think of to make this program an even better example of using geoProgrammer?
